Vicmarc V00769-3US VL300 2HP Wood Lathe

Vicmarc V00769-3US VL300 2HP Wood Lathe

$5,195.00
SKU
V00769-3US
Brand

Product Description

Please call 1-800-779-7458 to order.

VL300 SHORT SM EVS

The VL300 Short Stand Mount EVS (Electronic Variable Speed) lathe is a more economically priced version of the current VL300 ASM Lathe. The electronic variable speed drive gives up to 200% torque on low rpm and it comes with a powerful 1.5kw motor . The three-step pulleys provide 3 ratios 1:1 for small to medium size work; 1:1.5 for medium to large work; and 1:3 for large work.

The cast iron lathe is mounted on a 4mm thick steel plate stand, which has been designed with a 700mm wide footprint for stability and rigidity.

The short bed version has an optional 500mm or 1000mm bolt on extension facility. By bolting the extension on to the lathe the distance between centers would be either 1000mm or 1500mm.

Precision machined face on both ends of the bed for bolt on extension bed or swing away tailstock support.

Digital speed readout located below the headstock that displays the actual spindle RPM.

Hindged headstock door for ease of use and a new cast steel toolrest which has been machined with a more ergonomic profile.

Centre Height: 300mm
Swing Over Bed: 600mm
Distance Between Centers: 500mm
Work Height (Floor to Spindle Centre): 1130mm
Indexing Holes: 24
Headstock and Tailstock Spindle: No. 2 MT
Spindle Bearings: Taper Roller
EVS 10-3000 rpm: 3 Speeds
Toolrest Post Diameter: 30mm
Hole Through Headstock Spindle: 15mm
Hole Through Tailstock Spindle: 10.5mm
Quill Travel: 75mm
Net Weight: 229kg
Length x Width x Height(mm): 1150x790x1480

Standard Accessories

1x Faceplate 150mm
1x Live Centre
1x Tool Rests 300mm
1x 10mm Knockout Bar
1x Drive Dog
1x Spanner
1x Vicmarc Hat
1x Owner's Manual
