Evans 0138 Postforming Machine

(No reviews yet) Write a Review
  • Evans 0138 Postforming Machine
  • Evans 0138 Postforming Machine control box
MSRP: $34,500.00
— You save $15,500.00


Only used for one job, in great condition.

The Evans Machinery Model 0138 All Form is designed for the custom manufacturer doing doors, drawer fronts, desk tops, custom furniture, bar tops, service counters or any type of work that requires post forming. Model 0138 can wrap any type of Postform laminate or vertical grade laminate in a 90 degree, 180 degree or full 360 degree over all types of radius without set-up. The unique heated platen maintains pressure against the radius continuously throughout the forming process. The Model 0138 allows the freedom to use either contact adhesive or white glue (PVA).

Machine Specifications
Electrical 220v 1 Ph 4.5 KW
Motor 1/3 HP
Amps 20
Working Height 36"
Maximum 180º Wrap 3"
Maximum Length 98"
Air Requirement 100 PSI
Foot Print

140" x 50 "

Weight Crated 1900 lbs
